Fahrgestell LKW neu kaufen IVECO Trakker Chassis w/ Sleeping

Model description: IVECO Trakker Chassis w/ Sleeping Cab 6×4 – GVW 41 Ton, Wheelbase 4500 w/ Hub Reduction MY21 Chassis Cab Code Diesel

Type: AT380T42H

Cab Type: Sleep Cabin

Front Axle: 9 Ton

Rear Axle: 32 Ton

Vehicle Suspension Type: Mechanical Suspensions

Tyres: 20022-Pneumatic 325/95R24 20022

Drive Hand: LH Drive

Dimension: 9.52 x 2.55 x 3.10 m

Ground Clearance rear: 310 mm

Ground Clearance front: 337 mm

Chassis Length: 7.199 meters approx

Capacity Liters: 12,88

engine power: 420 E3

Expansion module

FMS Data Interface

External Sun Visor

Front semielliptic suspensions

Rear Dampers

630CC air compressor

Disk Wheel 24-8.5 for tyres 12.00R24

Rear Axle Ratio 5.56

Max Power(Hp/Kw)@Rpm-420/309

1500-1900

Max Torque (Nm/Mkg) 1900/194

900-1500

90A Alternator

Rear multileafs spring 13

Rear Anti-Roll Bar

Jacking Equipment

Rear Overhang 2080mm

Loads 9000-32000kgs

Low Air warning buzzer

Manual Battery Cut Out

PTO Pre equipment

Cross Axle Differential Lock

Radiator Guard

Rear suspension no spacer

Cross member D 120 kn

Delete rear mudguard

Mph/kph speedometer

Speed Limiter 90Km/H

Cluster kmh and mph indicator

Standard toolkit

Generic tow hook

Trailer coupl. - 2 line brakes

15 pin trailer plug

Towing version

Tyre inflation hose
