Sattelzugmaschine Volvo FH500 Aero I-Save 4x2 Euro6

Umweltplakette

Interne Fahrzeugnr.: FG500782, Mehr INFO unter:

+49 1636 633 037 Luis Lucena (Deutsch, English, Español, Français)

+48 669 808 888  Viktoria Sologubova (Polnisch, Russisch, Ukrainisch, English)

Large amount available

Mileage - 75.000 - 85.000 km

Smooth road conditions (at least 95% driving on surfaced roads)

Operating cycle Long Distance

Long distance transport cycle (driving pattern)

Predominantly flat operating topography

Complete superstructure & payload centre of gravity 0.5-1.0 m above top of

truck frame

Between 10-40% of the driven distance on roads/surfaces defined as dirty

Gross combination weight 44.0 tonnes

Box Body / Van Body Climate controlled (insulated walls)

Vehicle width 2600 mm

Chassis height medium - approx. 900 mm above ground level

Rear air suspension - one axle, driving

FH Aero Globetrotter XL, extra-high sleeper cab

Wheelbase 3800 mm

Euro 6 with High Torque EGR and particulate filter, turbocompound

Diesel engine, Euro 6, 12.8 litres, 500 hp/368 kW, 2810 Nm with

turbocompound

Volvo Engine Brake, VEB+ (high efficiency compression brake with exhaust

pressure governor, EPG)

I-Shift automated 12-speed gearbox, 2800 Nm

Rear single reduction solo axle - axle load 13 tonnes, GCW 44 tonnes, version F

Driving axle tyre dimension 315/70

Rear axle ratio 2.31

Fuel economy package for Euro 6 D13 engine

Power steering pump with variable displacement (extra valve)

Engine idle shutdown after one minute

I-Torque cruise control, optimized for fuel economy, I-Roll included

Airflow package with roof and side air deflectors and chassis fairings

Roof air deflector

Cab side air deflectors, long

Chassis fairings, extended

1 (10)

Volvo Trucks

!"#$%&'()*+,-./0123456789:;?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[]^_`abcdefghijklmnopqrstuvwxyz{|}~ OE

!"#$%&'()*+,-./0123456789:;?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[]^_`abcdefghijklmnopqrstuvwxyz{|}~ OE

Aerodynamic flaps on chassis fairings

Standard side underrun protection, aluminium

Driver convenience package, Selected

Static cornering lights

Two armrests on driver's seat

Vinyl armrest upholstery

Roof hatch, manually operated, tinted glass, rear opening 50 mm

Wipers rain sensor

Manually adjustable steering wheel with neck tilt

Living package, 2 beds (FH)

upper storage), net incl.

safety net included

Cab parking heater, 2 kW

Refrigerator 33-litre, with freezer and dividers, in drawer under bunk

Two bottle holders: one under dashboard centre section, one on lower bunk

drawer

Overlay mattress, 28 mm thick black textile

Interior white and red (night) light with smooth light transition at on/off and

dimmer

Information package, high (with side display)

Two-leaf front parabolic springs (normal stiffness)

Front axle load 7.5 tonnes

Front anti-roll bar, high stiffness

Rear axle load 13 tonnes

Rear anti-roll bar, normal stiffness

Air suspension with three ride heights

Without active steering

Disc brakes with light weight discs

Driving axle disc brake diameter 410 mm

EBS (Electronic Braking System), Medium package

Extra parking brake on one axle

Rear air springs

Frame rail section external height 266 mm

Frame thickness - web 6.5 mm / flange 6.5 mm

FRAME MATERIAL, RECYCLED, BIOENERGY PROCESSED STEEL

Without frame inner liner

Without protective cover for chassis-mounted pneumatic equipment

Battery box on left-hand side

Single battery system (2 batteries)

AGM batteries, 2x210 Ah

Without battery charger

Battery voltmeter, ammeter and battery status gauge with visual alerts

Battery reconditioner

Without ADR classification

Without ADR adaptation (transportation of dangerous goods)

Key remote controlled main switch

Right 405-litre, D-shaped aluminium fuel tank, 710 mm high

Left 650-litre, D-shaped aluminium fuel tank, 710 mm high

Fuel tank with basic ground clearance

AdBlue tank on right hand side

AdBlue tank: usable volume 90 litres, 710 mm high, mounted on chassis side

Without AdBlue tank cover

Lockable diesel and AdBlue filler caps

Fuel filling anti-spillage device

Horizontal silencer, rear exhaust outlet

Without extra exhaust heat shield

Two collapsible wheel chocks
